Low Profile SMD Inductor with 1 to 1,200nH Inductance and Large Current Capability for Compact PCB Layouts

5000
MOQ
Low Profile SMD Inductor with 1 to 1,200nH Inductance and Large Current Capability for Compact PCB Layouts
Kenmerken Galerij Productomschrijving Ga Nu Praten.
Kenmerken
Specificaties
Inductantie bereik: 1 tot 1.200 nH
Huidige capaciteit: Groot
Profielontwerp: Vaag
Bedrijfstemperatuur: -20 aan 85°C
Isolatieweerstand: >100 mΩ
Basis informatie
Plaats van herkomst: China
Merknaam: SHINHOM
Certificering: RoHS/ISO/UL/CE/IATF16949/CNAS
Modelnummer: AIML
Betalen & Verzenden Algemene voorwaarden
Levertijd: 2 ~ 8 weken
Betalingscondities: L/C, T/T
Productomschrijving
Chip Inductor with 1 to 1,200nH Inductance, Low Profile and Large Current
Product Overview

The Low-Profile Chip Inductor is a high-efficiency, magnetically shielded SMD component designed for high-current applications in compact PCB layouts. With low DCR and a shielded construction, it ensures minimal power loss, high reliability, and strong performance in space-constrained environments.

Featuring an inductance range from 1 to 1,200 nH, this SMD inductor supports a wide variety of power applications while maintaining stable operation across temperature and humidity variations.

Key Features
Inductance Range
1 to 1,200 nH, supporting versatile power designs
High Current Capability
Handles large currents in SMD power applications
Low-Profile Design
Ideal for compact and space-conscious PCB layouts
Magnetic Shielding
Reduces EMI interference and preserves signal integrity
Low Resistance
Minimizes deep power losses for efficient performance
Operating Temperature
-20 to 85°C (with heating coil)
Durability
Terminal strength verified after soldering; withstands vibration, humidity, and reflow soldering conditions
Safety
Dielectric strength tested at 100V DC; insulation resistance >100 MΩ
Applications
  • SMD power management circuits
  • Compact DC/DC converters and embedded systems
  • High-current surface-mount power designs
  • Automotive and industrial electronics requiring robust SMD inductors
label:

chip coil inductor

thin film inductor

chip power inductor
